PC-150 13.56 MHz USB NFC Reader/Writer with Dual SAM Slots
HF desktop reader/writer for MIFARE, DESFire, FeliCa, ICODE, CPU and NFC Forum Type 1–5 tags, with two SAM slots, 0–4 cm range and switchable USB HID/CDC.
- Two ISO/IEC 7816 SAM slots for secure key handling during card issuing
- ISO/IEC 14443A/B, 15693 and 18092 in one 13.56 MHz reader/writer
- Handles MIFARE Classic, DESFire EV1/EV2, Ultralight C, FeliCa, ICODE, CPU and NFC Forum Type 1–5
- USB at 12 Mbps, switchable HID or CDC; Windows, Linux, Android and macOS
- Active auto-read or passive command-driven read/write; firmware upgradable over USB
- Frequency
- 13.56 MHz
- Standards
- ISO/IEC 14443A/B, 15693, 18092, 7816
- SAM slots
- 2
- Interface
- USB 12 Mbps, HID / CDC
- Read range
- 0–4 cm
- Power
- 4.3–5.5 V via USB, ≤ 300 mA
Reply within 24 hours Tested before dispatch Worldwide shipping
13.56 MHz USB NFC Reader/Writer with Dual SAM Slots: overview
The PC-150 is a 13.56 MHz desktop reader/writer for card-issuing work that calls for secure key handling. Two ISO/IEC 7816 SAM slots accept secure access modules, the usual way to keep card keys out of the enrollment PC, while the RF side handles ISO/IEC 14443A/B, ISO/IEC 15693 and ISO/IEC 18092 credentials.
Supported cards and tags include MIFARE Classic, DESFire EV1/EV2, Ultralight and Ultralight C, FeliCa, ICODE, CPU cards and NFC Forum Type 1 to 5 tags. Cards are read at 0–4 cm, depending on the card and where the reader is placed.
The reader works in active mode, reporting cards as they are presented, or in passive mode, carrying out read and write commands sent by your software. The USB link runs at 12 Mbps and can switch between HID and CDC (virtual COM) operation. Host support covers Windows 10, 8.1, 8 and 7, Linux, Android and macOS, and a configuration tool plus USB firmware upgrades keep deployed units current.
Integration notes
Supply range is 4.3–5.5 V from USB. At 5 V the unit draws ≤ 250 mA in standby and ≤ 300 mA while working, so plug it into a full-power port rather than a bus-powered hub. It measures 110 × 80 × 16.9 mm, weighs about 169 g and is rated for −20 to +60 °C at 20–80% non-condensing humidity.
More features
- 0–4 cm read range; 110 × 80 × 16.9 mm, about 169 g
PC-150 specifications
RF & credentials
| Frequency | 13.56 MHz |
|---|---|
| Standards | ISO/IEC 14443A, ISO/IEC 14443B, ISO/IEC 15693, ISO/IEC 18092, ISO/IEC 7816 (SAM) |
| Cards and tags | MIFARE Classic, MIFARE DESFire EV1/EV2, MIFARE Ultralight, MIFARE Ultralight C, FeliCa, ICODE, CPU (microprocessor) cards, NFC Forum Type 1–5 tags |
| SAM slots | 2 |
| Read range | 0–4 cm (depends on card and installation) |
| Operations | Active card reading; passive read/write on host command |
Interfaces & software
| Host interface | USB |
|---|---|
| USB data rate | 12 Mbps |
| USB modes | HID or CDC (virtual COM), switchable |
| Operating systems | Windows 10, 8.1, 8, 7; Linux; Android; macOS |
| Configuration | Management tool for updating reader parameters |
| Firmware | Upgrade over USB |
Electrical
| Supply voltage | 4.3–5.5 V DC via USB |
|---|---|
| Current (at 5 V) | ≤ 250 mA standby, ≤ 300 mA operating |
Mechanical & environment
| Dimensions | 110 × 80 × 16.9 mm (±0.3 mm) |
|---|---|
| Weight | Approx. 169 g |
| Operating temperature | −20 to +60 °C (−4 to +140 °F) |
| Storage temperature | −40 to +80 °C (−40 to +176 °F) |
| Operating humidity | 20–80% RH, non-condensing |
| Certifications | None declared for the standard unit |
Supported NFC Forum tag types
| Tag type | Air interface | Typical chips |
|---|---|---|
| Type 1 | ISO/IEC 14443A | Legacy Type 1 tags |
| Type 2 | ISO/IEC 14443A | MIFARE Ultralight, Ultralight C, NTAG2xx |
| Type 3 | FeliCa (ISO/IEC 18092) | FeliCa |
| Type 4 | ISO/IEC 14443A/B | MIFARE DESFire EV1/EV2, CPU cards with NFC application |
| Type 5 | ISO/IEC 15693 | ICODE |
Order code
| SKU | Frequency | SAM slots | USB modes | Read range |
|---|---|---|---|---|
| PC-150-M-N | 13.56 MHz | 2 (ISO/IEC 7816) | HID / CDC, switchable | 0–4 cm |
Specifications can change between production batches. Confirm the current revision with us before placing volume orders.
Ordering options
Quote the SKU that matches your frequency, interface and mounting. Not sure? Send us your controller model and we will pick the variant for you.
| SKU | Configuration | Actions |
|---|---|---|
| PC-150-M-N | 13.56 MHz multi-protocol desktop reader/writer, 2 SAM slots, USB HID/CDC switchable, 0–4 cm range |
Where the PC-150 is used
- Issuing DESFire credentials with keys held in a SAM instead of on the enrollment PC
- Personalizing CPU cards for a campus or corporate access scheme
- Reading FeliCa, ICODE and MIFARE credentials at one visitor-registration desk
- Writing data to NFC Forum tags for asset labels or patrol checkpoints
Gym & 24/7 Fitness Club Access Control Hardware
Gym access control system hardware for 24/7 clubs: fob and wristband readers, face and QR terminals, anti-passback controllers and no-touch exit buttons.
RFID Asset & Tool Tracking
Build an RFID asset tracking system: on-metal, ceramic and tie-on tags matched to each asset, handheld audits, smart cabinets and IP67 HF heads for tooling.
PC-150 FAQ
What are the SAM slots for?
They take ISO/IEC 7816 secure access modules, so keys used while issuing cards can live in the SAM instead of in host software. Your issuing application must support SAM-based key handling to use them.
Does the PC-150 read 125 kHz cards?
No. It works at 13.56 MHz only. For sites that also use 125 kHz EM cards, choose the dual-frequency PC-140.
Which operating systems are supported?
Windows 10, 8.1, 8 and 7, Linux, Android and macOS, connected over USB in HID or CDC mode.
What read range should I expect?
0–4 cm, depending on the card type and the surface or enclosure around the reader.
Is it CE or FCC certified?
No certifications are declared for the standard unit. If your market requires specific marking, contact us before ordering so we can confirm what is available.
